HPE ProLiant Compute DL320 Gen12 6515P 2.3GHz 16c 1P 1x64GB-R 8SFF MR408i-o 2x1000W PS EU Server
Lifecycle Obsolete Date 31-07-2029 Specifications System fan features 7x High Performance Fans Included drives None ship standard, 8 SFF supported Processor name Intel® Xeon® 6515P (16 core, 2.30 GHz, 72 MB L3, 150W) Included memory 64 GB (1x64 GB, 6400 MT/s) Memory type HPE DDR5 Smart Memory Expansion slots Up to 6 PCIe Gen5, and 2 OCP 3.0 with Rich IO Processor, for detailed descriptions reference the QuickSpecs Warranty 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of on-site support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://www.hpe.com/support/ProLiantServers-Warranties. Additional HPE support and service coverage, to supplement the product warranty, is available at: https://www.hpe.com/support. Security UEFI Secure Boot and Secure Start support. Intel® Software Guard Extensions (SGX) support. Intel® Trust Domain Extensions (Intel® TDX). Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Optional Trusted Supply Chain, iLO Security modes, Chassis Intrusion detection and Bezel Locking kits. For full security features refer to the QuickSpecs. Power supply type 2x HPE 1000W M-CRPS Titanium Hot Plug Power Supply Kit Accelerators Maximum of 2 double-wide or 4 single-wide in the front or 1 single-wide in the rear, depending on model Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (optional subscription available) Storage controller HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller HPE NS204i-u v2 480GB NVMe Hot Plug Boot Optimized Storage Device Optical drive type Optional DVD-ROM / DVD-RW Optical Drive Network controller Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE Form factor 1U Rack Processor cache 72 MB L3 Processor core available 16 core Processor number 1 processor included Processor speed 2.30 GHz Quickspecs QuickSpecs QuickSpecs (PDF) QuickSpecs QuickSpecs (HTML) Overview Do you need a 1U single-socket rackmount server, that maximizes rack utilization while mitigating virtualization risks in power-constrained environments? The HPE ProLiant DL320 Gen12 maximizes your rack utilization while mitigating virtualization risks in power-constrained environments. Power your workloads with a server providing greater expansion capabilities compared to previous generations. The latest Intel® Xeon® 6 processors with up to 144 cores, increased memory capability (up to 4 TB), and high-speed PCIe Gen5 help provide a high performance solution with better datacenter efficiency. Features HPE iLO 7 supports quantum-resistant (PQC) algorithms and signs HPE ProLiant Compute Gen12 firmware with algorithms approved by CNSA 2.0, which enhances resilience against potential future attacks by quantum computers. The HPE ProLiant Compute DL320 Gen12 server is an excellent choice for cloud-native, containerized, and scale-out environments and other workloads that require high core density and efficient multi-threading. Optimized Performance for your Workloads: Accelerated, Open, and Efficient Harness major compute performance. The HPE ProLiant Compute DL320 Gen12 server is powered by Intel® Xeon® 6700P/6500P-series processors that support up to (86) P-cores or up to (144) E-cores. Services provided under Operational Services include: HPE Flexible Capacity, HPE Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive Services, and multi-vendor coverage. HPE IT investment solutions help you transform into a digital business with IT economics that align with your business goals. Benefit from real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs. Industry-leading Services and Ease of Deployment The HPE ProLiant Compute DL320 Gen12 server comes with a complete set of HPE Services, delivering confidence, reducing risk, and helping you realize agility and stability. HPE Services simplify all stages of the IT journey. Advisory and Transformation Services professionals understand your challenges and design an effective solution. Professional Services enable rapid deployment of solutions and Operational Services provide ongoing support. Next-Level Security, Chip to Cloud Transform business operations and pivot your team from reactive to proactive with global visibility and insight through a self-service console. Automate tasks for efficiency in deployment, instant scalability, and seamless, simplified support and lifecycle management reducing tasks and shortening maintenance windows. Enjoy advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x 16 PCIe Gen5 and and front or rear OCP NIC or controller add-in cards slots to improve I/O throughput and reduce latency. Utilize 16 DIMM slots for up to 4 TB DDR5 memory with increased memory bandwidth and performance. Intuitive Cloud Operating Experience: Simple, Self-service, and Automated HPE ProLiant Compute DL320 Gen12 servers are engineered for your hybrid world. The new ProLiant Compute Gen12 servers simplify the way you control your business’s compute—from edge to cloud—with a cloud operating experience. From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Compute Gen12 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements. Silicon root of trust from HPE establishes a zero-trust security framework at the silicon level to ensure firmware integrity. Continuous protection detects compromised servers and prevents them from booting if malicious code is found. Edge servers are safeguarded with default IDevID certificates. HPE ProLiant Compute servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of operating system, application and data connections, providing the fastest path to bring a server back online and into normal operations. Intel® Xeon® 6 processors add hardware- and software-assisted security features such as Intel® Software Guard Extensions (SGX) for application isolation and Trusted Domain Extensions (TDX) for VM isolation, which help protect the server hardware foundation and safeguard data in memory. Media Explore the HPE ProLiant Compute DL320 Gen12 server Video exploring the new HPE ProLiant Compute DL320 Gen12 server Compatible products Microsoft Windows Server 2025 16-core Standard Reseller Option Kit WW ESD LTU HPE 2.4TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty 512e Multi Vendor HDD HPE 300GB SAS 12G Mission Critical 10K SFF BC 3-year Warranty Multi Vendor HDD INT Xeon 6517P CPU for HPE HPE 3.84TB NVMe Gen4 Mainstream Performance Read Intensive SFF BC U.3 Static V2 Multi Vendor SSD Red Hat Resilient Storage 2 Sockets or 2 Guests 1 Year Subscription E-LTU HPE 1.92TB SAS 12G Read Intensive SFF BC Value SAS Multi Vendor SSD ARUBA 8325-48Y8C FB 6 F 2 PS BDL HPE 3.2TB NVME MU SFF BC U.3 PM1735A SSD SSD HPE P64844-B21, 1.92TB, NVMe HPE 3.2TB SAS 24G Mixed Use SFF BC Multi Vendor SSD MS WS25 16C Std ROK EU SW HPE MR416I-P GEN11 SPDM STORAGE CNTLR Red Hat Enterprise Linux for SAP for Virtual Datacenters 5yr Subscription 24x7 Support E-LTU Microsoft Windows Server 2025 50 Users CAL WW LTU MS WS25 16C Std Add Lic WW SW RHEL Svr 2 Sckt 4 Gst 5yr 24x7 E-LTU HPE LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable HPE ProLiant DL3X0 Gen11 1U Standard Heat Sink Kit Adaptor Wired HPE BCM57504 HPE LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable HPE SN1610Q 32Gb 1-port Fibre Channel Host Bus Adapter HPE 7.68TB SATA RI SFF BC MV SSD HPE Bezel Lock Kit HPE C13 - C14 WW 250V 10Amp Flint Gray 2.0m Jumper Cord SSD HPE P40497-B21, 480GB, SATA HPE Smart Storage Hybrid Capacitor with 145mm Cable Kit RH HA 2 Sckt/2 Gst 5yr E-LTU Red Hat Enterprise Linux for SAP for Virtual Datacenters 3yr Subscription 24x7 Support E-LTU RHEL Svr 2 Sckt 4 Gst 3yr 9x5 E-LTU Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 3 Year Subscription 9x5 Support E-LTU MS WS25 5Usr CAL WW LTU SSD HPE P40502-B21, 480GB, SATA HPE 7.68T NVMERI SFF BC U.3ST V2 MV SSD HPE C13 - C14 WW 250V 10Amp 2.0m Jumper Cord RHEL Svr 2 Sckt 4 Gst 5yr 9x5 E-LTU HPE DDR4 DIMM Blank Kit Red Hat Enterprise Linux for SAP (Physical/Virtual Nodes) 5yr Subscription 24x7 Support E-LTU HPE BladeSystem c-Class Virtual Connect 1G SFP SX Transceiver HPE NS204i-u v2 960GB NVMe Hot Plug Boot Optimized Storage Device Red Hat Enterprise Linux Server 2 Sockets 1 Guest 1 Year Subscription 9x5 Support E-LTU HPE LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable HPE DL3XX GEN11 1U BEZEL KIT BCM 57414 10/25GbE 2p SFP28 Adptr RHEL Svr 2 Sckt 4 Gst 1yr 9x5 E-LTU RH RS 2 Sckt Unltd Gst 3yr E-LTU MS WS25 RDS 5USR CAL WW LTU HPE DL3XX Gen11 Easy Install Rail 2 Kit Red Hat Enterprise Linux for SAP (Physical/Virtual Nodes) 5yr Subscription 9x5 Support E-LTU HP OV 3yr 24x7 Supp Flex E-LTU HPE 100Gb QSFP28 MPO SR4 100m Transceiver Microsoft Windows Server 2025 2-core Standard Additional License WW SW Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 1 Year Subscription 9x5 Support E-LTU HPE 100GbE QSFP28 SR4 100m Transceiver HPE SN1610Q 32Gb 2-port Fibre Channel Host Bus Adapter HPE 3.84TB SATA 6G Read Intensive SFF BC Multi Vendor SSD MS WS25 4C Std Add Lic WW SW HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 5 Year Subscription 24x7 Support E-LTU SSD HPE P40504-B21, 1.92TB, SATA Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T Adapter for HPE Red Hat Enterprise Linux for SAP (Physical/Virtual Nodes) 3yr Subscription 24x7 Support E-LTU HPE 96W Smart Storage Lithium-ion Battery with 145mm Cable Kit SSD HPE P40499-B21, 1.92 TB, SATA, SSD Microsoft Windows Server 2025 1 Device CAL WW LTU Red Hat High Availability 2 Sockets or 2 Guests 1 Year Subscription E-LTU HPE BladeSystem c-Class 10Gb SFP+ SR Transceiver SSD HPE P40503-B21, 960GB, SATA Hard Disk HPE P53561-B21, 600 GB, SAS, 10000 rpm MS WS25 RDS 1Usr CAL WW LTU SSD HPE CM7, 1.92TB, NVMe HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features Spade Blank Kit HPE Gen9 LFF HDD Spade Blank Kit Red Hat High Availability 2 Sockets or 2 Guests 3 Year Subscription E-LTU RHEL Svr 2 Sckt 4 Gst 1yr 24x7 E-LTU Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 5 Year Subscription 24x7 Support E-LTU HPE 1.8TB SAS 10K SFF BC 512E MV HDD MS WS25 1USR CAL WW LTU HPE Proliant DL/ML Ons Startup Service RHEL Svr 2 Sckt 1 Gst 1yr 24x7 E-LTU HPE ProLiant Compute DL3XX Gen12 1U 8SFF Front Display Port/USB/Optical Drive Enablement Kit HPE ProLiant DL/ML Install Service HPE 9.5mm SATA DVD-RW Optical Drive HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE HPE 1.92TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 PM1733a SSD MLX MCX631102 10/25GBE 2P SFP28 ADPTR Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 5 Year Subscription 9x5 Support E-LTU HPE ProLiant DL300 Gen10 Plus 1U Cable Management Arm for Rail Kit HPE BladeSystem c-Class 10Gb SFP+ LR Transceiver Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 3 Year Subscription 24x7 Support E-LTU SUSE Linux Enterprise High Availability Extension 1-2 Sockets 3 Year Subscription E-LTU HPE C19 - C20 WW 250V 16Amp 0.7m Black Locking Power Cord Red Hat Resilient Storage 2 Sockets or 2 Guests 3 Year Subscription E-LTU RHEL Svr 2 Sckt 4 Gst 3yr 24x7 E-LTU HPE C19 - C20 WW 250V 16Amp 2.5m Jumper Cord SSD HPE P40498-B21, 960 GB, SATA, SSD Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 1 Year Subscription 24x7 Support E-LTU HPE LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable RH HA 2 Sckt Unltd Gst 1yr E-LTU Red Hat Enterprise Linux Server 2 Sockets or Guests 5 Year Subscription 9x5 Support E-LTU SSD HPE P40510-B21, 960 GB, SAS, SSD RH RS 2 Sckt Unltd Gst 1yr E-LTU HPE C13 - KSC- 8305 KR 250V 10Amp 1.83m Power Cord Red Hat Enterprise Linux for SAP for Virtual Datacenters 5yr Subscription 9x5 Support E-LTU HPE Small Form Factor Hard Drive Blank Kit HPE GREENLAKE COM EN 3Y UP PROLIANT AAS HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features Microsoft Windows Server 2025 50 Devices CAL WW LTU Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 3 Year Subscription 24x7 Support E-LTU HPE MR216i-p Gen11 x16 Lanes without Cache PCI SPDM Plug-in Storage Controller Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 1 Year Subscription 9x5 Support E-LTU RH HA 2 Sckt Unltd Gst 3yr E-LTU Microsoft Windows Server 2025 4-core Datacenter Additional License WW SW Red Hat Resilient Storage 2 Sockets Unlimited Guests 5yr Subscription E-LTU HPE Mobile USB DVD-RW Optical Drive HPE 1.6TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PM1735a SSD RH HA 2 Sckt Unltd Gst 5yr E-LTU HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features Adaptor Wired HPE BCM57416 Red Hat Enterprise Linux for SAP (Physical/Virtual Nodes) 3yr Subscription 9x5 Support E-LTU Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE BCM 57412 10GBE 2P SFP+ OCP3 ADPTR HPE C13 - CEE-VII EU 250V 10Amp 1.83m Power Cord Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ Adapter for HPE Microsoft Windows Server 2025 10 Users CAL WW LTU Red Hat Enterprise Linux for SAP for Virtual Datacenters 3yr Subscription 9x5 Support E-LTU Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 1 Year Subscription 24x7 Support E-LTU SSD HPE P40508-B21, 3.84 TB, SAS HPE 1.83m 10A C13-UL Dom Pwr Cord RH RS 2 Sckt/2 Gst 5yr E-LTU HPE MR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features HPE MR216i-o Gen11 SPDM Storage Cntlr HPE Aruba Networking CX 8100 24x10G Base-T 4x10G SFP+ 4x40/100G QSFP28 FB 3Fan 2AC PSU Sw Bdl HPE 7.68TB SAS 12G Read Intensive SFF BC Value SAS Multi Vendor SSD HPE 25Gb SFP28 SR 100m Transceiver Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 3 Year Subscription 9x5 Support E-LTU Broadcom BCM57414 Ethernet 10/25Gb 2-port SFP28 OCP3 Adapter for HPE HPE 1.2TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty Multi Vendor HDD HPE 9.5mm SATA DVD-ROM Jb Gen9 Kit Documents Enterprise server acceleration from edge to data center HPE ProLiant Compute DL320 Gen12 QuickSpecs Future-proofing with more power and less energy – phoenixNAP
