BIOS typeUEFI AMI
BIOS memory size128 Mbit
ACPI version5.1
System Management BIOS (SMBIOS) version2.3
PCI Express x16 (Gen 3.x) slots2
Number of M.2 (M) slots2
PCI Express x1 (Gen 2.x) slots4
PC health monitoringFan, Temperature, Voltage
Motherboard chipsetAMD B450
Chip audioRealtek ALC892 / Realtek ALC897
CertificareFCC, CE, ErP/EuP
Canale audio7.1 channels
Componentă pentruPC
Sisteme Windows compatibileWindows 10 x64
Format placă de bazăATX
Familie chipsetAMD
DirectX version12.0
Rezoluție maximă4096 x 2160 pixels
HDCPDa
Parallel processing technology supportCrossFireX, Quad-GPU CrossFireX
Număr monitoare suportate3
Conectori USB 2.02
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
Front panel audio connectorDa
ATX Power connector (24-pin)Da
CPU fan connectorDa
12V power connectorDa
Number of COM connectors1
TPM connectorDa
RGB LED pin headerDa
Number of SATA III connectors6
Number of chassis fan connectors3
Cod vamal (HS)84733020
Supported memory clock speeds2133,2400,2667,2933,3200 MHz
ECC сompatibilityECC & Non-ECC
Număr sloturi memorie4
Memory slots typeDIMM
Unbuffered memoryDa
Canale memorieDual-channel
Tipuri de memorie compatibileDDR4-SDRAM
Maximum internal memory128 GB
LAN controllerRealtek RTL8111H
Ethernet LANDa
Wake-on-LAN readyDa
Tip interfață EthernetGigabit Ethernet
Wi-FiNu
Drivers includedDa
Cabluri incluseSATA
Bundled softwareASRock A-Tuning
ASRock Polychrome SYNC
ASRock XFast LAN
Porturi DVI-D0
Număr porturi HDMI1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
DisplayPort version1.2
Porturi DisplayPort1
Versiune HDMI1.4
Porturi USB 2.02
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Producător procesorAMD
Socket procesorSocket AM4
Maximum number of SMP processors1
Compatible processor seriesAMD Athlon, AMD Ryzen 3000 Series, AMD Ryzen 5000 Series
Porturi Ethernet LAN (RJ-45)1
PS/2 ports quantity1
VGA (D-Sub) ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
RAID supportDa
Interfețe stocare compatibileM.2, SATA III
Niveluri RAID0, 1, 10
Adâncime224 mm
Lățime30.5 mm
MB-FormatATX
RAM-Slots4
MB-SocketAM4
PCI-Ex162
USB34-8
CPU încorporatNu
PCI-Ex11
PCI0
Serial-or-ParalelNo/No
