BIOS typeUEFI AMI
Format placă de bazămicro ATX
Familie chipsetAMD
Chip audioRealtek ALC887
Componentă pentruPC
Canale audio7.1 channels
Motherboard chipsetAMD B550
Placă video integratăDa
HDCPDa
DirectX version12.0
Graphics card familyAMD
Graphics cardRadeon Vega
Conectori USB 2.04
Peripheral (Molex) power connectors (4-pin)1
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
TPM connectorDa
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
Number of SATA III connectors4
Number of SATA II connectors0
Number of Parallel ATA connectors0
Front panel audio connectorDa
ATX Power connector (24-pin)Da
CPU fan connectorDa
Number of chassis fan connectors2
Cod vamal (HS)84733020
ECC сompatibilityECC & Non-ECC
Memory slots typeDIMM
Unbuffered memoryDa
Număr sloturi memorie2
Tipuri de memorie compatibileDDR4-SDRAM
Canale memorieDual-channel
Maximum internal memory64 GB
Wake-on-LAN readyDa
Tip interfață EthernetGigabit Ethernet
Wi-FiNu
LAN controllerRealtek RTL8111H
Ethernet LANDa
Greutate465 g
Drivers includedDa
Compatible processor seriesAMD Ryzen 3000 Series
Socket procesorSocket AM4
Producător procesorAMD
Maximum number of SMP processors1
eSATA ports quantity0
Firewire (IEEE 1394) ports0
Porturi USB 2.02
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Porturi DVI-D1
Număr porturi HDMI1
VGA (D-Sub) ports quantity1
PS/2 ports quantity1
Interfețe stocare compatibileM.2, SATA III
Lățime230 mm
Înălțime70 mm
Adâncime201 mm
CPU încorporatNu
PCI0
Serial-or-ParalelNo/No
