BIOS typeUEFI AMI
BIOS memory size256 Mbit
Clear CMOS jumperDa
PCI Express x1 (Gen 3.x) slots2
PCI Express x16 (Gen 3.x) slots1
Number of M.2 (M) slots1
Sisteme Windows compatibileWindows 10 x64, Windows 11
Canale audio7.1 channels
Componentă pentruPC
Format placă de bazămicro ATX
Familie chipsetAMD
Motherboard chipsetAMD A520
Chip audioRealtek ALC887 / Realtek ALC897
Parallel processing technology supportNot supported
Number of chassis fan connectors1
TPM connectorDa
Number of EATX power connectors2
12V power connectorDa
S/PDIF out connectorDa
Number of COM connectors1
Conectori USB 2.02
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
Number of SATA III connectors4
Front panel audio connectorDa
ATX Power connector (24-pin)Da
CPU fan connectorDa
Cod vamal (HS)84733020
Memory slots typeDIMM
Unbuffered memoryDa
Număr sloturi memorie2
Tipuri de memorie compatibileDDR4-SDRAM
Canale memorieDual-channel
Maximum internal memory64 GB
ECC сompatibilityECC
Ethernet LANDa
Wake-on-LAN readyDa
Wi-FiNu
LAN controllerRealtek RTL8111H
Tip interfață EthernetGigabit Ethernet
Cabluri incluseSATA
Supported processor socketsSocket AM4
Compatible processor seriesAMD Ryzen™ 3, AMD Ryzen™ 5, AMD Ryzen™ 7
Socket procesorSocket AM4
Producător procesorAMD
Porturi USB 2.02
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Număr porturi HDMI1
Versiune HDMI2.1
USB connector typeUSB Type-A
Porturi DVI-D0
VGA (D-Sub) ports quantity1
Microphone inDa
Porturi Ethernet LAN (RJ-45)1
Headphone outputs3
PS/2 ports quantity1
Niveluri RAID0, 1, 10
Număr unități de stocare5
Interfețe stocare compatibileM.2, SATA III
RAID supportDa
Supported storage drive typesHDD & SSD
Lățime226 mm
Adâncime221 mm
MB-Formatmicro-ATX
MB-SocketAM4
RAM-Slots2
PCI0
Serial-or-ParalelNo/No
USB34-8
CPU încorporatNu
PCI-Ex11
PCI-Ex161
