Number of M.2 (M) slots2
PCI Express x16 (Gen 4.x) slots2
PCI Express x1 (Gen 3.x) slots3
PCI Express x16 slots2
PCI Express x1 slots3
CuloareNegru
Motherboard chipsetIntel B760
Sisteme Windows compatibileWindows 10 x64, Windows 11 x64
Format placă de bazăATX
Familie chipsetIntel
Canale audio7.1 channels
Chip audioRealtek ALC897
Componentă pentruPC
Placă video integratăNu
TPM connectorDa
Number of SATA III connectors4
Number of SATA II connectors0
Number of SATA connectors0
USB 3.2 Gen 1 (3.1 Gen 1) connectors3
S/PDIF out connectorDa
Conectori USB 2.04
Număr sloturi memorie4
Memory slots typeDIMM
Maximum internal memory192 GB
Tipuri de memorie compatibileDDR5-SDRAM
ECC сompatibilityNon-ECC
Canale memorieDual-channel
Wi-FiDa
Standard Wi-FiWi-Fi 6E (802.11ax)
Ethernet LANDa
Tip interfață Ethernet2.5 Gigabit Ethernet
BluetoothDa
LAN controllerDragon RTL8125BG
Versiune Bluetooth5.3
mSATA ports quantity0
Socket procesorLGA 1700
Producător procesorIntel
Compatible processor seriesIntel® Celeron®, Intel® Pentium® Gold
Porturi Ethernet LAN (RJ-45)1
DisplayPort version1.4
Număr porturi HDMI1
Versiune HDMI2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
Porturi USB 2.04
S/PDIF out portDa
Porturi DisplayPort1
RAID supportDa
Niveluri RAID0, 1, 5, 10
Interfețe stocare compatibileM.2, SATA
Lățime243.8 mm
Adâncime304.8 mm
MB-FormatATX
MB-Socket1700
PCI-Ex10
RAM-Slots2
PCI-Ex165
USB34-8
Onboard-CPUNu
PCI0
Serial-or-ParalelNo/No
