HDMI1
Bluetooth5.4
ThunderboltNu
RJ-451
USB 2.04
Suport audio7.1
DisplayPort1
USB 3.2 Gen2 tip A3
USB Tip C1x USB 3.2 Gen 2 tip C
Audio jacks6
BIOS Flashback1
Conectori speciali2× Wi Fi Antenna
CuloareAlb
1st M.2 largest key size2280
2nd M.2 largest key size2280
3rd M.2 largest key size2280
PCI Express x16 (Gen 5.x) slots1
PCI Express x4 (Gen 4.x) slots1
Number of M.2 (M) slots3
1st M.2 highest PCI Express generation5.0
2nd M.2 highest PCI Express generation4.0
3rd M.2 highest PCI Express generation4.0
Sisteme Windows compatibileWindows 10 x64, Windows 11
Canale audio7.1 channels
Familie chipsetAMD
Chip audioRealtek ALC897
Componentă pentruPC
Format placă de bazăATX
Motherboard chipsetAMD B850
Interfata graficaPCI Express x16 5.0
SATA III4
Placa video integrataNecesita procesor cu tehnologia AMD Radeon Graphics
Placa audio integrata7.1 Audio
NGFF (M.2)3
Placa retea integrata2.5 Gbps
Chipset audioRealtek ALC897
Chipset reteaRealtek RTL8125BG
BIOSSAPPHIRE CORE BIOS
Procesoare suportateAMD Ryzen 7000/8000/9000 Series
FormatATX
Recomandat GamingDa
Alte specificații1x PCIe 5.0 M.2, 2x PCIe 4.0 M.2
Parallel processing technology supportNot supported
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
Number of SATA III connectors4
ATX Power connector (24-pin)Da
CPU fan connectorDa
Front panel connectorDa
RGB LED pin headerDa
12V power connectorDa
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Serial port headers1
Number of chassis fan connectors3
Conectori USB 2.01
Number of water pump connectors1
Audio connectorDa
Number of CPU fan connectors1
Number of RGB LED pin headers3
Memorie SuportataDDR5
Capacitate maxima memorie RAM256 GB
TehnologieDual channel
Sloturi memorie4
Frecvente suportatePana la 8000 MHz(OC)
Memorie maximă128 GB
Tip MemorieDDR4
Tipuri de memorie compatibileDDR5-SDRAM
Maximum internal memory256 GB
Maximum internal memory per slot64 GB
Supported memory clock speed (max)8000 MHz
Număr sloturi memorie4
Memory slots typeDIMM
Canale memorieDual-channel
Ethernet LANDa
Wi-FiDa
Standard Wi-FiWi-Fi 7 (802.11be)
Tip interfață Ethernet2.5 Gigabit Ethernet
LAN controllerDragon RTL8125BG
Versiune Bluetooth5.4
Antenna includedDa
Porturi DVI-D0
Porturi DisplayPort1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
Porturi USB 2.04
Număr porturi HDMI1
ChipsetB850
Producator chipsetAMD
Socket procesorAM5
Producător procesorAMD
Compatible processor seriesAMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Socket procesorSocket AM5
Supported processor socketsSocket AM5
WiFi-AP antenna jack2
VGA (D-Sub) ports quantity0
Line-inDa
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB connector typeUSB Type-A, USB Type-C
Porturi Ethernet LAN (RJ-45)1
Microphone inDa
Headphone outputs6
PCI Express 5.01 (x16)
Header USB 3.0Da
PCI Express 4.02 (x16) (1x x4, 1x x2)
Dimensiuni (L x l, cm)30.5 x 24.4 cm
Supported storage drive typesHDD & SSD
Număr unități de stocare7
Interfețe stocare compatibilePCI Express 4.0, PCI Express 5.0, SATA III
GamingNu
Tip slot interfata graficaPCIe 4.0 x16
Soclu ProcesorNA (integrated CPU)
Chipset audio integratRealtek
Model ChipsetB850
Adâncime24.4 mm
Lățime30.5 mm
USB31
MB-SocketAM5
PCI-Ex10
RAM-Slots4
MB-Formatmicro-ATX
Onboard-CPUDa
PCI-Ex161
PCI2
