CertificareCE, FCC, RoHS
Forwarding rate7.4 Mpps
Tabelă adrese MAC2048 entries
Jumbo frames supportDa
Jumbo frames16000
Store-and-forwardDa
Switching capacity10 Gbit/s
Packet buffer memory1 MB
CuloareNegru
Montare în rackNu
Indicatoare LEDDa
Wall mountableDa
Housing materialOțel
Cod vamal (HS)85176990
Tip switchUnmanaged
Switch layerL2
Quality of Service (QoS) supportDa
Multicast supportDa
Tipuri de cabluCat3, Cat4, Cat5, Cat5e
MAC address auto-aging supportedDa
Full duplexDa
MAC address auto-learning supportedDa
Standarde de rețeaIEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Auto MDI/MDI-XDa
Flow control supportDa
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Auto-negotiationDa
Suport 10GNu
Umiditate de funcționare10 - 90%
Heat dissipation7.83 BTU/h
Temperatură de depozitare-40 - 70 °C
Umiditate de depozitare5 - 90%
Temperatură de funcționare0 - 40 °C
User guideDa
Cabluri incluseAC
Tip ambalajCutie
Installed SFP+ modules quantity0
Gigabit Ethernet (copper) ports quantity5
Porturi Ethernet RJ-455
Tip porturi Ethernet RJ-45Gigabit Ethernet (10/100/1000)
Power connectorDC-in jack
Power supply includedDa
Curent de intrare0.6 A
Frecvență de intrare AC50 Hz
Tensiune de intrare AC220 V
Power consumption (max)2.3 W
Power over Ethernet (PoE)Nu
IGMP snoopingDa
Înălțime25 mm
Adâncime98 mm
Lățime100 mm
LAN port typeGigabit
